Total 13 / 1 page

원형 목록

  • 13
    TGR
    DC Current 측정 (±40A~±400A) 공급전원 : +05V 기준전압 : +2.5V 출력 : ±1.5V, ±2V 자세히 보기
  • 12
    PL-A,S
    Reted Current : 25AT ~ 250AT DC or AC Output Signal : ±4V ±1% at If=F.S. Supply Voltage : ±12V or ±15V ±5% Accuracy : ±1.0% at IPN, TA = 25℃ Linearity : ±1.0% of Vh at If = F.S. Response Time : 5㎲ ~ 20㎲ Thermal Drift : ±0.1% /℃ 자세히 보기
  • 11
    LM-A,S,D
    Reted Current : 40AT ~ 400AT DC or AC Output Signal : ±4V ±1% at If=F.S. Supply Voltage : ±12V or ±15V ±5% Accuracy : ±1.0% at IPN, TA = 25%, ±1.5% Linearity : ±1.0% of Vh at If = F.S. Response Time : 5㎲ ~ 20㎲ Thermal Drift : ±0.1% /℃ 자세히 보기
  • 10
    TM-A,S,D,R
    Reted Current : 40AT ~ 400AT DC or AC Output Signal : ±4V ±1% at If=F.S. Supply Voltage : ±12V or ±15V ±5% Accuracy : ±1.0% at IPN, TA = 25℃ Linearity : ±1.0% of Vh at If = F.S. Response Time : 5㎲ ~ 20㎲ Thermal Drift : ±0.1% /℃ 자세히 보기
  • 9
    TM3-A,S
    Rated Current (F.S.) : 40A ~ 600A Output Voltage : ±04V±1% at If Zero Current Offset : Within ±20mV at If = 0 Linearity of Output : Within ±1.0% of Vh at If : F.S Supply Voltage : ±15V ±5% Response Time : 7㎲ec Max. at di/dt = F.S./㎲ec Frequency Range : DC ~ AC10KHz and 15KHz Max 자세히 보기
  • 8
    TM4-A,S
    Rated Current (F.S.) : 40AT ~ 400AT DC or AC Output Voltage : ±04V±1% at If Zero Current Offset : Within ±20mV at If = 0 Supply Voltage : ±15V ±5% Response Time : 5㎲ec Max. at di/dt = F.S./㎲e Frequency Range : DC ~ AC20KHz and 30KHz Max 자세히 보기
  • 7
    TK-A,S,D,R
    Reted Current : 40AT ~ 600AT DC or AC Output Signal : ±4V ±1% at If=F.S. Supply Voltage : ±12V or ±15V ±5% Accuracy : ±1.0% at IPN, TA = 25℃ Linearity : ±1.0% of Vh at If = F.S. Response Time : 7㎲ ~ 20㎲ Thermal Drift : ±0.1% /℃ 자세히 보기
  • 6
    TKS
    Rated Current(F.S.) : 120A ~ 300A Output Signal : +4V ±1% at If Zero Current Offset : Within +3 → +50mV at If = 0 Linearity of Output : Within ±1.5% of Vh at If : F.S Supply Voltage : +15V ±5% Response Time : 60㎲ec Max. at di/dt = F.S./㎲ec Frequency Range : DC ~ AC5KHz and 20KHz Max 자세히 보기
  • 5
    AI
    Rated Current(F.S.) : 250A ~ 600A Output Signal : +10V-p ±1% at If Zero Current Offset : Within +3 → +30mV at If = 0 Linearity of Output : Within ±1.0% of Vh at If : F.S. Supply Voltage : +15V ±5% Response Time : 20㎲ec Max. at di/dt = F.S./㎲ec Frequency Range : DC ~ AC5KHz and 10KHz Max. 자세히 보기
  • 4
    HTC1-A,S,R
    Rated Current (F.S.) : 200A ~ 900A Output Voltage : ±04V ±3% at If Zero Current Offset : Within ±20mV at If = 0 Linearity of Output : Within ±1.0% of Vh at If : F.S Supply Voltage : ±12V or ±15V ±5% Response Time : 7㎲ec Max. at di/dt = F.S./㎲ec Frequency Range : DC ~ 10KHz Max 자세히 보기
  • 3
    WM
    Reted Current : 40AT ~ 300AT DC or AC Output Signal : ±4V ±1% at If=F.S. Supply Voltage : ±12V or ±15V ±5% Accuracy : ±1.0% at IPN, TA = 25℃ Linearity : ±1.0% of Vh at If = F.S. Response Time : 5㎲ ~ 20㎲ Thermal Drift : ±0.1% /℃ 자세히 보기
  • 2
    3W-A,D
    Reted Current : 25AT ~ 200AT DC or AC Output Signal : ±4V ±1% at If=F.S. Supply Voltage : ±12V or ±15V ±5% Accuracy : ±1.0% at IPN, TA = 25℃ Linearity : ±1.0% of Vh at If = F.S. Response Time : 5㎲ ~ 20㎲ Thermal Drift : ±0.1% /℃ 자세히 보기
  • 1
    CKPR
    Rated Current (F.S.) : 50A ~ 750A Output Voltage : Ref.2.5[V]±02V±1.5% at If Zero Current Offset : Ref.2.5[V], Within ±20mV at If = 0 Linearity of Output : Within ±1.0% of Vh at If : F.S. Supply Voltage : +05V ±5% Vh - Response Time : 15㎲ec Max. at di/dt = F.S./㎲ec Frequency Range : DC ~ 10KHz 자세히 보기
